Apart from common functions (ON, OFF, Timer, Push), it can be used as a signal repeater. This function will be valued in case you want to expand the number of controlled circuits or in area's with difficult RF signal ranges.
"ON" FUNCTION - after each push of the transmitter, the receiver relay will switch on or will stay switched on.. The "OFF" FUNCTION - after each push of the transmitter, the receiver relay will switch off or will stay switched off. The "PUSH" FUNCTION - the receiver relay will switch on during the holding of the transmitter button – max. 1 min. "TIMER" FUNCTION - after pushing of the transmitter, the receiver relay will switch on for a preset time period.
- easy set up and adjustment
- advanced functionality programming by using Poseidon® Asistent software
- compatible with all the Poseidon® transmitters
- suitable for switching of any type of load
- optional external antenna extension
- works as an RF signal repeater
Connection to the power supply as well as to the receiver outputs is made via Wieland connectors.(connectors not included)
